LED Display

Product : LED Display
Model : MYS-3461
Shell Dimensions : 30*14*7mm
Emitted Color : red
Polarity : CA
Product description : Customized products according to requirements

Model:MYS-3461

  • Wide voltage adaptation、low power consumption、high sensitivity、Excellent anti-interference characteristics;
  • Applications:TV, set-top box, VTR, audio, digital photo frame, household electrical appliance, air conditioner, toy,lamp, and all appliances that require infrared remote controlling;

1.Absolute Maximum Ratings:

Parameter Symbol Maximum RatingUnit
Power DissipationPd50mW
Peak Forward CurrentIfp60mA
Continuous Forward CurrentIfm20mA
Reverse VoltageVR5V
Operating Temperature RangeTopr-20 → +85
Storage Temperature RangeTstg-20 → +85
Static VoltageVar2000V
  • Lead Sodering Temperature:260℃ for 3 seconds
  • For operation above 25℃, The Ifm Ifp & Pd must be derated, the Curent derating is –0.36mA/℃ for DC
    drive and -0.86mA/℃ for Pulse drive, the power dissipation is -0.75mW/℃. The product working current
    must not more than the 60% of the Ifm or Ifp according to the working temperature.

2.Optoelectronic Parameter:

ParameterTest CONDITINGSymbolMinTypeMaxUnit
Luminous IntensityIF=20mAIv232528Mcd
Forward VoltageIF=20mAVF1.92.02.5V
REVERSE CurrentVR = 5VIR50uA
Peak WavelengthIF=20mAλD630633637nm
Spectral BandwidthIF=20mA△λ5nm
View AngleIF=20mA2θ1/260Deg.

3.Storage & Soldering Condions

Store with care. Storing the units in bad condition will cause the reflector sheet and decrease it’s adhesive power. Storage the products under the condition :temperature ( 25℃ ± 10℃ ) and humidity (65℃ CRH±20℃ CRH) our recommendation.
A. The Soldering Temperature is 260±5℃ and Soldering Time should be less than 3 sec, and soldering iron power should be less than 30W.
B. The soldering point should be farther than 1.6mm from boby.

4.Product display:
